[1318917-1] 2.2Pitch 24P Wire End Male Housing

Specifications

Material

Package Type

tape and reel‌、 ‌tube packaging‌、Tape and Reel Package

Note For Wafer Connectors, FPC Connectors, FAKRA Connectors, and HSD Connectors, please contact customer service to confirm the final packaging method based on product specifications, size, and quantity requirements.

Drawing/Model

Product Features

This 2.2 Pitch 24P Wire End Male Housing features a robust construction with integrated locking tabs that produce a positive, vibration-resistant connection when mated with the corresponding female header, maintaining electrical continuity in applications subject to mechanical shock and continuous vibration. The housing is manufactured from high-temperature-resistant thermoplastic that maintains dimensional stability through soldering and overmolding processes encountered during harness production, ensuring consistent mating performance across production lots. Terminal cavities incorporate polarization features that prevent incorrect terminal insertion, reducing the risk of miswired harnesses that could cause equipment malfunction, safety hazards, or costly field repair campaigns. The connector's compact envelope allows efficient use of panel space in multi-connector installations, while still providing adequate wire entry clearance for ergonomic crimping and assembly operations. Optional strain relief accessories attach to the housing's cable entry face, distributing mechanical loads away from crimp joints and extending harness service life. Cavity numbering molded into the housing exterior facilitates accurate wire placement during harness fabrication.

Application Scenarios

The 2.2 Pitch 24P Wire End Male Housing serves as a cable-side connector in automotive audio amplifiers and navigation platforms, organizing the multiple power supply, speaker output, and data communication conductors within a single connector body that simplifies harness routing and reduces the number of discrete wire connections. Medical imaging equipment manufacturers employ this housing for routing control signals and data streams between rotating gantry electronics and stationary processing units in diagnostic systems that require reliable signal transmission across slip ring interfaces. Industrial test equipment designers incorporate it for data acquisition front-end modules that require numerous input channels within a compact connector footprint, enabling scalable channel count configurations. In commercial aviation ground support systems, the housing links diagnostic interfaces to aircraft avionics test points for pre-flight system verification. The male housing design provides a straightforward and reliable method for field-serviceable connections, allowing technicians to disconnect and reconnect cable assemblies during troubleshooting without disturbing permanent wiring or requiring specialized tools.

Why Choose [1318917-1] 2.2Pitch 24P Wire End Male Housing

• 24-pin plug housing of this 2.2Pitch 24P Male Housing provides reliable multi-circuit connectivity for control wiring and equipment harnesses in compact form.

• Positive locking engagement of this 24P Male Housing prevents unintended disconnection during operation, sustaining continuity across all circuits reliably.

• Molded from automotive-grade polymer resistant to chemicals and temperature extremes, this 24P Male Housing delivers consistent dimensional and mechanical performance.

• Pitch standard of this 2.2Pitch 24P Male Housing ensures broad terminal compatibility, reducing sourcing complexity and supporting efficient high-volume harness assembly.

• Backed by a proven supply chain with technical support, this 24P Wire End Male Housing enables smooth program integration and reliable series supply for manufacturing.
