2.0PH Wafer Shrouded Vertical Header: Pin Protection for Harsh Duty

In automotive, industrial, and battery assemblies, the connector is often the first part to fail — and the pins are usually the reason why. The 2.0PH Wafer Shrouded Vertical Header is built to remove that failure point before it reaches the field.

When a pin bends during placement or seats incorrectly during mating, the result is scrap, rework, or a connection that drifts under load. The shrouded, covered housing of the 2.0PH Wafer Shrouded Vertical Header wraps the contact pins on every side, so they cannot deform during automated assembly or mis-align during mating. A polarized shroud also blocks reverse insertion — a small feature that prevents a common, costly mistake on the line.

Mounted vertically, the 2.0PH Wafer Shrouded Vertical Header rises straight off the PCB, keeping the wire exit clean and the layout predictable. That matters in dense control boards where every millimeter of routing space counts. The shroud's walls also shield the pins from accidental contact and mechanical stress during handling and transport.

Durability is engineered in, not added on. The LCP insulator carries a UL94 V-0 rating and holds its shape through reflow soldering, while gold-plated contacts over a nickel underplate resist corrosion across a −40°C to +105°C operating range. The result is a 2.0 mm wire-to-board connection that stays stable through heat, vibration, and humidity — the conditions that define harsh duty.

From battery management systems and motor controls to in-vehicle sensor interfaces, the 2.0PH Wafer Shrouded Vertical Header fits where connections must survive both the assembly line and the field. It is a 2.0 mm pitch wire-to-board header in the PH series — a spacing that balances pin density with the manufacturability engineers rely on.

Specify the 2.0PH Wafer Shrouded Vertical Header where uptime is non-negotiable and the margin for connection error is zero. Reach our team for samples and the full drawing to validate it on your next board.
