2.2Pitch Male and Female Connector

Specifications

Material

Package Type

tape and reel‌、 ‌tube packaging‌、Tape and Reel Package

Note For Wafer Connectors, FPC Connectors, FAKRA Connectors, and HSD Connectors, please contact customer service to confirm the final packaging method based on product specifications, size, and quantity requirements.

Drawing/Model

Product Features

This 2.2 Pitch Male and Female Connector pair provides a complete interconnect solution with matched contact geometry that ensures proper engagement force, contact wipe, and electrical continuity across all positions when the two halves are mated. The male pin contacts feature a precision-formed geometry with a tapered entry that guides the pin into the female socket, reducing the risk of contact damage during mating misalignment and ensuring smooth engagement in applications where visual access to the mating interface is limited. Female socket contacts incorporate a multi-beam design that provides consistent normal force against the male pin surface throughout the rated mating cycle life, maintaining low and stable contact resistance for reliable signal integrity and power delivery. Both connector housings are molded from glass-reinforced thermoplastic that provides the dimensional stability necessary to maintain contact cavity alignment across the operating temperature range, from extreme cold conditions to sustained high-temperature exposure in engine compartment and industrial environments. The mated pair features a primary latch system that provides positive retention with audible and tactile engagement feedback, giving assembly operators confirmation that the connectors are fully seated during production line installation. A secondary locking device is available as an additional safeguard against accidental unmating due to vibration, cable pull forces, or mechanical shock in demanding automotive and industrial operating conditions. Polarization features on both connector halves ensure correct mating orientation, preventing reverse insertion that could cause electrical damage to connected circuits. The 2.2mm pitch provides adequate creepage and clearance distances for the voltage and current ratings typical of automotive signal and low-power distribution applications.

Application Scenarios

The 2.2 Pitch Male and Female Connector pair is extensively used in automotive electronic control units, providing the primary wire-to-board interconnect for engine management systems, transmission controllers, and body electronics modules where the matched contact pair ensures reliable signal and power transmission between the wiring harness and the circuit board. Industrial automation equipment manufacturers apply these connectors in motor drive interfaces and sensor connection modules where the robust contact system and secure latch mechanism provide reliable performance in environments with vibration, temperature cycling, and electrical noise. In commercial vehicles, the connector pair links the main wiring harness to dashboard instrument clusters and body control modules where the mated pair must maintain electrical continuity under the sustained vibration of highway operation. Building automation systems utilize the connectors for controller-to-sensor interfaces and actuator drive connections where the complete mating pair provides a serviceable disconnect point for system maintenance and component replacement. The connector pair also serves in power tool and appliance electronics, linking motor control boards to user interface panels and power input modules where the reliable contact system ensures safe and consistent product operation.

Why Choose 2.2Pitch Male and Female Connector

• Matched male and female contact geometry of this connector pair ensures proper engagement force and contact wipe, providing reliable electrical continuity across all positions upon mating.

• Multi-beam female socket design maintains consistent normal force against the male pin throughout the rated cycle life, ensuring stable contact resistance for signal and power circuits.

• Primary latch with audible and tactile feedback provides positive mating confirmation during production assembly, reducing the risk of incomplete connections in blind installation locations.

• Polarization features on both connector halves prevent reverse insertion, safeguarding connected circuits from electrical damage due to incorrect mating orientation.

• The 2.2mm pitch provides adequate creepage and clearance for automotive and industrial voltage ratings, supporting reliable performance in both signal and power distribution applications.
