34、6098-5277
| Pitch：2.20mm | |
| Pins：12P | |
| Mounting Method：Vertical SMT、Horizontal |
| Insulator Material：PBT（white） |
tape and reel、 tube packaging、Tape and Reel Package
Note For Wafer Connectors, FPC Connectors, FAKRA Connectors, and HSD Connectors, please contact customer service to confirm the final packaging method based on product specifications, size, and quantity requirements.
![[6098-5277] 2.2Pitch 12P Female Housing](http://iororwxhimpllk5p-static.micyjz.com/cloud/pkBpkKlmliSRqllrlrklkq/34.jpg "2.2Pitch 12P Female Housing")
The core capability of the 2.2mm Pitch 12P Female Housing is consolidation: a dozen separate leads end in a single wire-side body that a technician can disconnect and reconnect without disturbing anything around it. That matters most where a machine carries several short runs of related signals and the cabinet or enclosure is already tight. Rather than three or four small plugs competing for the same panel space, one body takes the whole group, which trims the parts count, shortens assembly time, and cuts the number of places where a lead can be swapped by mistake. Contacts are held in a fixed sequence, so a wiring diagram maps directly onto the connector and a fault can be traced from either end of the loom. The shell is keyed to its mate, which blocks a partly seated or wrong plug from going home and keeps two similar looms from being cross-connected during a hurried install. Because the body is molded in a rigid engineering thermoplastic, it resists the deformation that loose handling and repeated mating can cause, so contacts keep their alignment through bundling, shipping, and the first few service cycles. Natural molding keeps the part at the resin's own base color, with no added colorant to declare. Taken together, these traits turn a busy bundle of wires into one assembly that behaves like a single component.
Where the 2.2mm Pitch 12P Female Housing earns its place is on equipment that travels, vibrates, and still has to be serviced in the field. A precision planter running across a field is a good example: row-unit sensors, seed-tube monitors, and down-pressure feedback all report back to one controller, and a dozen conductors leaving that cluster through a single body means a technician can swap a row unit without unpicking the whole implement loom. Solar trackers tell a similar story, where drive feedback and position sensing at each axis have to land at a combiner box mounted outdoors, and where a plug that separates as one unit is far easier to replace than a set of individual leads. Inside a warehouse, shuttles and guided vehicles carry their own dense looms, and every extra connector is another failure point on a machine that cannot afford downtime mid-shift. What these settings have in common is a group of related signals that belong together, a panel or enclosure with no room to spare, and a maintenance crew that would rather unplug one body than trace twelve wires.
1. The 2.2mm Pitch 12P Female Housing suits machines that have to keep running, where one serviceable plug beats a bundle of loose leads.
2. Twelve circuits in a single wire-side body cut the harness parts count while keeping the 2.2mm pitch your existing drawings already use.
3. PBT molding holds cavity geometry stable through repeated mating, so contact position survives the handling a service cycle brings.
4. Natural, pigment-free molding leaves the shell at its base resin color for programs that do not need color coding.
5. Field examples include precision-agriculture implements, solar tracker control wiring, and warehouse vehicles, where the same plug has to take movement and repeated service.
FAQs
Q: Is the 2.2mm Pitch 12P Female Housing the right choice for a twelve-circuit control harness?
A: It fits harnesses where a dozen related signal or low-power leads should leave an enclosure as one serviceable body, which is common on mobile and field-installed equipment. If your run is shorter, a lower position count in the same 2.2mm pitch family keeps to the same layout practice; if it is longer, step up inside the family rather than adding a second connector type.
Q: What does natural color mean on this 12P female housing?
A: Natural means the housing is molded in its base PBT resin with no pigment added, so the part carries the resin's own color rather than a specified one. That suits programs with no color-coding requirement; if your harness uses color to identify circuits, confirm the finish you need before the housing is ordered.
Q: How do I confirm the terminals are fully seated in this twelve-position housing?
A: Crimp each contact to its lead first, then push it in from the wire side until it stops, and give every lead a light pull to check retention before the plug is mated. Cavity positions run in a fixed order, so seat them against the wiring diagram and inspect the row once the last terminal is in.
Q: What mates with this 12P PBT female housing?
A: It is the wire-side half of a 2.2mm pitch pair and mates with the matching male housing or board header of the same pitch and position count. Check position count, row layout, and keying against the mating part, and note that housings from the same 2.2mm family in other position counts are not interchangeable.
