3、101032-***111-1
| Current Rating：0.5A | Insulation Resistance：500MΩ/min |
| Voltage Rating：50V | Withstand Voltage：200 V AC/rms |
| Contact Resistance：≤40mΩ | Operating Temperature Range：-40℃~+105℃ |
| Plastic material：LCP / UL94V-0 | Terminal material：phosphor bronze |
tape and reel、 tube packaging、Tape and Reel Package
Note For Wafer Connectors, FPC Connectors, FAKRA Connectors, and HSD Connectors, please contact
customer service to confirm the final packaging method based on product specifications, size, and quantity requirements.
The standout trait of this connector is its unshielded vertical top-contact build, which keeps the part simple and low-cost while still returning board space that horizontal layouts waste. The vertical SMT footprint lifts the flex cable off the board plane, so signal lines route upward and free the surrounding area for denser component placement. Top-contact terminals meet the FPC from above, matching cable assemblies that approach the connector from the top side and simplifying visual alignment during hand or automated insertion. Gold-plated contact surfaces preserve a clean, low-resistance interface that resists oxidation, so the link stays stable through reflow heat, storage, and daily operation rather than degrading after a few cycles. An LCP housing rated UL94V-0 holds its shape through lead-free soldering and meets flame-safety requirements for consumer, industrial, and automotive use. Surface-mount terminations align with standard pick-and-place and solder profiles, so the part drops into existing SMT lines without special fixtures or process changes. Because the body carries no shielding, it suits standard signal links where EMI control is handled elsewhere in the stack, letting designers choose a leaner interconnect when a shielded version would be unnecessary weight and cost. For builds that need a compact, top-entry flex link without paying for shielding they do not need, the FPC 0.5mm Pitch Vertical SMT Top Contact No Shield Connector delivers a practical, dependable answer.
On an automotive display or infotainment board, the FPC that bridges the panel to the main controller often has to enter from the top of the stack, and a connector that accepts that approach without stealing horizontal board area keeps the module within its tight enclosure. In a portable medical monitor, the flex carrying sensor or display signals runs through a sealed, regularly handled shell where a small, simply seated link reduces assembly time on the line and removes a common point of failure. Industrial control boards tuck these connectors into panels where space is rationed between relays, connectors, and the board edge, and a vertical top-entry part lets the cable rise clear of neighboring components instead of crossing them. In each case the need is the same: a compact flex junction that seats from above, asks nothing special of the process, and keeps the signal honest. The FPC 0.5mm Pitch Vertical SMT Top Contact No Shield Connector fits these roles precisely, where vertical routing and a lean, unshielded body are exactly what the layout calls for.
1. The FPC 0.5mm Pitch Vertical SMT Top Contact No Shield Connector's upward cable entry matches top-approach FPC routing, so engineers design the flex path without compromising board layout.
2. Gold-plated contacts hold a stable, low-resistance interface and resist corrosion, keeping the signal clean through reflow and field service.
3. Automotive-grade quality — built under IATF 16949 and ISO management standards, supporting programs that demand documented process control.
4. LCP UL94V-0 housing survives lead-free reflow and meets flame-safety requirements across consumer, industrial, and automotive use.
5. Standard SMT assembly — surface-mount terminations follow common pick-and-place and solder profiles, so the part drops into existing lines with no special tooling.
Q: How do I insert and seat the FPC cable in the FPC 0.5mm Pitch Vertical SMT Top Contact No Shield Connector?
A: Align the FPC/FFC with the connector entry and slide it in straight until it reaches the stop, conductor side facing the top contacts. Keep the cable square to the slot and avoid tilting, then verify it is fully seated before the board is soldered. Because this is a top-contact part, the cable approaches from above, so confirm the cable's gold fingers face the contact side shown on the product drawing.
Q: What does "no shield" mean for this 0.5mm vertical top-contact FPC connector, and when is it the right choice?
A: The housing carries no EMI shielding, so it is intended for standard signal links where interference control is handled elsewhere in the design. Choose it when your layout does not require a shielded interconnect and you want a leaner, lower-cost part; if your application is noise-sensitive, a shielded FPC connector would be the better fit.
Q: Is this 0.5mm top-contact FPC connector suitable for automotive or industrial programs?
A: It is produced under IATF 16949 and ISO quality management systems and rated for an operating range of -40C to +105C, which covers typical automotive cabin, industrial, and consumer environments. Confirm the specific grade and qualification documentation against your program's release requirements.
Q: What soldering or reflow care does this connector need during assembly?
A: The LCP UL94V-0 body is built for lead-free SMT reflow, so follow a standard profile suited to LCP housings and avoid prolonged hand-soldering heat on the plastic. Only process the board after the connector is mounted and the cable is removed, to protect the contacts and the housing from damage.
