[ZE05-16DS-HU/R] 2.0pitch 16P Spacing Connector Assembly

Material

Package Type

tape and reel‌、 ‌tube packaging‌、Tape and Reel Package

Note For Wafer Connectors, FPC Connectors, FAKRA Connectors, and HSD Connectors, please contact customer service to confirm the final packaging method based on product specifications, size, and quantity requirements.

Drawing/Model

Product Features

This 2.0 Pitch 16P Connector Assembly features a 16-position cavity layout on a 2.0mm pitch, providing high circuit density within a connector envelope that is significantly more compact than equivalent designs on wider pitch standards, making it an effective choice for electronic control units with high pin-count requirements and limited mounting space. The housing incorporates a primary latch that provides audible and tactile confirmation of full mating engagement, giving assembly operators positive feedback that the connector is properly seated during production line installation. A secondary lock device is available as an additional safeguard, preventing terminal back-out and ensuring that all 16 contacts maintain their seated position under the vibration and mechanical shock conditions typical of automotive and industrial operating environments. The housing is molded from glass-reinforced thermoplastic that provides the mechanical strength and dimensional stability required to maintain cavity alignment across the full operating temperature range, from cold-soak conditions to sustained under-hood heat exposure. Each cavity is designed to accept precision-stamped crimp terminals that provide gas-tight connections with low and stable contact resistance, ensuring reliable signal and power transmission across the 16 circuit paths. The connector system includes polarization and keying features that prevent cross-mating with other connectors in the same vehicle or equipment, reducing assembly errors and simplifying harness routing in complex electrical systems. The compact 2.0mm pitch enables a narrower overall connector width compared to 2.5mm or 3.0mm pitch alternatives, freeing board space for additional components or enabling smaller overall PCB dimensions.

Application Scenarios

The 2.0 Pitch 16P Connector Assembly is extensively deployed in automotive body electronics, including door control modules, seat adjustment systems, and climate control units where the 16-circuit capacity accommodates the multiple sensor inputs, motor drive outputs, and communication signals required by these complex subsystems. Industrial equipment manufacturers utilize this connector in programmable logic controller I/O modules and distributed control system nodes where high pin-count wire-to-board connections are needed on compact circuit boards within standardized DIN-rail housings. In commercial vehicles, the connector links trailer brake controllers, lighting interfaces, and diagnostic ports where the 16-position capacity supports comprehensive signal and power routing within a single connector body. Building automation systems apply the connector for HVAC zone controller interfaces and fire alarm panel connections where the multi-circuit design consolidates numerous signal paths into a compact, serviceable disconnect point. The connector also serves in agricultural equipment and construction machinery, linking operator control stations to hydraulic valve banks, implement sensors, and GPS guidance modules in environments subject to extreme vibration and environmental exposure.

Why Choose [ZE05-16DS-HU/R] 2.0pitch 16P Spacing Connector Assembly

✅ **High-Density 2.0mm Pitch Design**   The 16-position 2.0mm pitch layout delivers high circuit density in a compact envelope, supporting complex signal and power routing in space-constrained electronic control units and PCB applications.

✅ **Audible Primary Latch Confirmation**   Primary latch with audible engagement feedback provides positive confirmation of proper mating during production line assembly, reducing the risk of incomplete connections and improving quality control.

✅ **Secondary Lock Prevents Terminal Back-Out**   Secondary lock device prevents terminal back-out under vibration and mechanical shock, ensuring all 16 contacts maintain reliable electrical continuity in demanding automotive and industrial environments.

✅ **Durable Glass-Reinforced Housing**   Glass-reinforced thermoplastic housing provides dimensional stability across the operating temperature range, preserving cavity alignment for consistent mating performance and long-term reliability.

✅ **Polarization Prevents Cross-Mating**   Polarization and keying features prevent cross-mating with similar connectors, eliminating assembly errors in complex vehicle, equipment, or electronic wiring harness systems.
