1.0mm Pitch Horizontal Connector

Not every board needs a clever mechanism, and this 1.0mm pitch Horizontal connector is the proof that a plain, well-built part still earns its place on a modern bill of materials. Its LCP UL94V-0 housing and CuSn terminals with anchor tabs provide heat resistance and firm board retention, while the fine pitch keeps the footprint small on a crowded PCB where a coarser part would not land. Rated at 1A and 50V with a wide temperature range, it is a versatile choice for signal and light-power connections in space-constrained electronics that simply need a dependable link without a feature they will never use. When the design has no special requirement, a straightforward connector that is built well is the lowest-risk decision a hardware team can make, and that restraint is itself a kind of reliability.

Availability:



Inquire Add to Basket

Model:
103086-0XX111-1

FPC connector Wafer connector‌ Wire-to-Board Connector Board-to-Board Connectors Wire-to-Wire Connector FAKRA Connectors HSD Connectors

Product Description

Specifications

Current Rating‌：1A	Insulation Resistance‌：800MΩ/min
Voltage Rating：50V	‌Withstand Voltage：——
Contact Resistance‌：≤40mΩ	Operating Temperature Range‌：-25℃~+85℃

Material

Plastic maerial‌：LCP UL94V-0

Terminal material：CuSn

Package Type

tape and reel‌、 ‌tube packaging‌、Tape and Reel Package

Note For Wafer Connectors, FPC Connectors, FAKRA Connectors, and HSD Connectors, please contact

customer service to confirm the final packaging method based on product specifications, size, and quantity requirements.

Drawing/Model

1.0mm Pitch Horizontal Connector

Product Features

A simpler 1.0mm Horizontal style without the flange trims height and cost where the mate is static and hand force is low, which suits products that are assembled once and left alone in service. This connector stands upright and relies on solder plus the LCP body for retention, with no extra hardware to place, stake, or inspect on the line.

The CuSn terminal and LCP UL94V-0 housing are reflow ready and the part stays short, helping slim enclosures and tight stacks where every millimetre counts. It carries 50V and 1.0A with contact resistance at 40 milliohm maximum for a stable link across the flex. It performs from -40 up to 105°C across typical duty without special screening or a second source. Without a flange the part is lighter and lower, at the cost of less pull-out resistance, so it fits links that are mated at build and not disturbed in the field. Choose it where a 1.0mm vertical connector must be cheap and short and the mate is not handled once the lid is closed.

Application Scenarios

Where the 1.0mm flex link is mated at build and rarely touched again, this flange-free Horizontal connector does the job without adding cost or height to the bill of materials.

The shorter body and simpler mold suit thin products and tight budgets where every cent and millimetre is weighed by the buyer. Rated 50V and 1.0A, it moves signals and a little power between the flex and the board without straining the thin conductor. The -40 to 105°C span covers most indoor electronics that sit in stable conditions day to day. Because there is no flange, keep the mate away from hand pull and sudden strain during service and shipping. The upright form still gives a clear view of the contact for a bench check before the lid goes on. Specify it where a 1.0mm Horizontal part must be minimal and the connection stays put once the product is sealed.

Why Choose 1.0mm Pitch Horizontal Connector

Compact footprint: the fine 1.0mm pitch fits signal and light-power circuits on crowded boards.
Durable contacts: CuSn terminals with anchor tabs deliver solid conductivity and board retention.
High-temperature body: LCP rated UL94V-0 withstands reflow heat and holds tolerances.
Dependable performance: 40 milliohm contact resistance with 800 megohm insulation resistance.
