1.0mm Pitch FPC Vertical Polarized Flip-Lock Connector

Reversed insertion can quietly damage circuits, and this 1.0mm pitch FPC vertical polarized flip-lock connector is built to stop that from happening. A keyed, polarized housing lets the flex cable seat only one way, while the flip-lock actuator then clamps it for a firm, low-resistance hold that survives handling and transport. The body is natural LCP rated UL94V-0 for flame retardance and heat resistance, with a black LCP lock bar for durable actuation, and the contacts are CuSn with nickel, tin, and gold plating for stable conductivity that does not drift over time. Vertical entry saves board space, and a 50V/1A rating with a wide temperature range makes it a safe, compact choice for products where correct orientation matters as much as retention. For high-volume lines and field-serviceable goods, the keyed design turns a common assembly mistake into something the hardware simply will not permit.

Availability:



Inquire Add to Basket

Model:
101096-****1-1

FPC connector Wafer connector‌ Wire-to-Board Connector Board-to-Board Connectors Wire-to-Wire Connector FAKRA Connectors HSD Connectors

Product Description

Specifications

Current Rating‌：1.0 A	Insulation Resistance‌：800MΩ/min
Voltage Rating：50 V	‌Withstand Voltage：200 V AC/min
Contact Resistance‌：≤40mΩ	Operating Temperature Range‌：-40℃~+105℃

Material

Plastic maerial‌：LCP Natural UL94V-0

Terminal material：CuSn

Package Type

tape and reel‌、 ‌tube packaging‌、Tape and Reel Package

Note For Wafer Connectors, FPC Connectors, FAKRA Connectors, and HSD Connectors, please contact

customer service to confirm the final packaging method based on product specifications, size, and quantity requirements.

Drawing/Model

1.0mm Pitch FPC ZIF Locking Vertical SMT In-Line Type

Product Features

Conserving board space while keeping terminations accessible is the job of this 1.0mm pitch FPC connector, and its vertical entry does exactly that. Its polarized geometry keys the flat flex cable so it can only seat in the correct orientation, and the flip-lock actuator then clamps the cable for a firm, low-resistance hold that resists pull-out during service.

The housing is molded from natural LCP rated UL94V-0 for flame retardance and heat resistance, paired with a black LCP lock bar for durable actuation that does not fatigue after many cycles. Contacts are CuSn with a nickel underplate and tin finish, and the solder tabs add a gold flash for reliable board attachment that tolerates reflow. Electrically it is rated at 50V AC(rms)/DC and 1A AC(rms)/DC, with 40 milliohm maximum contact resistance, 50V AC dielectric withstanding, and 800 megohm minimum insulation resistance for steady performance.

The vertical entry conserves board space, and a minus 40 to 105 degree range keeps it dependable through thermal cycling on the line and in the field. By combining polarity protection with a secure flip lock, the part removes a frequent cause of scrap and rework, which is worth more on a high-volume line than any single spec line.

Application Scenarios

This polarized flip-lock FPC connector suits compact devices where correct cable orientation is critical and board space is limited, such as camera modules, display assemblies, and multi-board consumer electronics that are built in volume.

The keyed design is especially valuable on high-volume lines and in field-serviceable products, where it guards against reversed insertion that could damage circuits and trigger costly returns. Its UL94V-0 LCP body handles reflow and warm operating conditions, making it a fit for dense gadgets and compact instruments that share an enclosure with heat sources.

With a 50V/1A rating and a minus 40 to 105 degree range, it reliably carries signal and light-power flex connections in equipment that must tolerate handling and temperature swings, from handheld units to fixed, temperature-variable installations. The polarity key also shortens operator training, since the correct way to load the cable is the only way the part will accept it.

Why Choose 1.0mm Pitch FPC Vertical Polarized Flip-Lock Connector

Mis-mate protection: the polarized, keyed design ensures the flex cable seats only in the correct orientation.
Secure actuation: the flip-lock bar clamps the cable for a firm, low-resistance hold.
Flame-retardant body: natural LCP rated UL94V-0 resists heat and flame during reflow and service.
Reliable contacts: CuSn terminals with nickel, tin, and gold plating maintain stable conductivity.
Space-saving and robust: vertical entry with a 50V/1A rating across a minus 40 to 105 degree range.
